| Model | Power rating | Frequency range | Main Line VSWR | Coupling Line VSWR | Coupling | Coupling Accuracy | Directivity | Isolation | Insertion Loss | Connector | Stock |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
30 |
400-6000 |
1.3Max 1.2Typ |
1.3Max 1.2Typ |
30±1.5 |
±1.0 |
12Min 16Typ |
|
1.0 |
SMA-F |
|
|
|
30 |
400-6000 |
1.35Max 1.2Typ |
1.35Max 1.2Typ |
20±1.5 |
±1.0 |
12Min 16Typ |
|
1.2 |
SMA-F |
||
|
30 |
400-6000 |
1.35Max 1.2Typ |
1.35Max 1.2Typ |
16±1.5 |
±1.0 |
12Min 16Typ
|
|
1.4 |
SMA-F |
||
|
200 |
130-960 |
1.3 |
1.3 |
6±1.5 10±2.0 20±2.0
30±2.0 |
|
|
|
|
N-F |
Coaxial Coupler
