| Model | Power rating | Frequency range | Return loss/VSWR | Insertion loss | Rejection | Impedance | Application | Connector | Dimensions | Stock | |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
30 |
698-716 |
14 |
1.0 |
≥50dB@607MHz/≥50dB@807MHz |
50 |
Indoor |
N-F |
||||
|
30 |
1848-1910 |
14 |
1.5 |
≥50dB@1630MHz/≥50dB@2130MHz |
50 |
Indoor |
N-F |
||||
|
30 |
3300-3900 |
14 |
1.0 |
≥50dB@1600MHz/≥50dB@5400MHz |
50 |
Indoor |
N-F |
||||
|
100w |
700-1000 |
1.5 |
0.6 |
≥75@1500-4000MHz |
50 |
Indoor |
N-F |
||||
|
250 |
815-915 |
1.4 |
0.6 |
≥40dBc@1630-2745MHz |
50 |
Indoor |
SMA-F |
||||
|
10 |
12000-18000 |
1.8 |
1.0 |
≥50dBc@24000-36000MHz; |
50 |
Indoor |
SAM-F |
||||
|
0.5 |
8000-12000 |
1.8 |
1.2 |
≥55dBc@DC-7000MHz; ≥55dBc@13000-20000MHz; |
50 |
Indoor |
0.4mm Glass Insulators |
||||
|
2 |
1070-1090 |
1.3 |
2.5 |
≥43dB@1280MHz ≥43dB@880MHz |
50 |
Indoor |
SMA-F |
Band-Pass-Filter
